Key Specification Sheet

PP50 grass and gravel grids are heavy-duty interlocking plastic grids used for ground reinforcement. This can be for trafficking applications including hardworking car parking, paths, walkways and fire access lanes. PP50 paving grids create a stable, reinforced and permeable load-bearing surface.

Key Information

  • Dimensions: 580mm x 580mm x 50mm (L x W x D)
  • Weight: Each piece is 2kg – 6kg per m² (+/-2%)
  • Nominal cell dimensions: 67mm x 67mm (+/-2%)
  • Parking bay marker: White 78 x 78mm marker (92mm on diagonal)
  • Connection method: Secure male-to-female hook connection
  • Cell wall thickness: 4mm (+/-2%)
  • Cell openness %: 89%
  • Polymer: Recycled polyethylene
  • Colour: Black and green (other colours are available upon request)
  • Material feature: UV-stabilised plastic
  • Load bearing capacity (installed): 500 tonnes per m² (Tested to UNI CEI EN ISO/IEC 17025 certification)
  • Working temperature: -40⁰c to +40⁰c
  • Product control: Tested to ISO 9000
  • Traffic loading capacity: 20-tonne wheel load SWL (Tested to DIN 1072 & UNI CEI EN ISO/IEC 17025 certification)
  • Pavers per m²: Three

All data figures are nominal and are given in good faith. Suregreen Limited reserve the right to amend any data without prior notice. Product variances are provided as a guide and normal production and product characteristics are within these parameters.


To purchase PP50 or any other Suregreen permeable pavers please visit our shop section of the website or click here - Suregreen permeable pavers
