Introduction to GR Mesh

Grass Reinforcement Mesh

Introduction to GR14 and GR11 Protection Mesh

Suregreen GR11 and GR14 grass reinforcement meshes have been specially designed, using carefully selected high-density plastics, to allow permanent trafficking to grassed areas where and when this would not normally be considered.  Our grass reinforcement meshes achieve this by reinforcing and protecting existing grass areas against traffic damage (both vehicle and pedestrian wear and rutting) whilst keeping the natural look of grass cover.

Grass reinforcement meshes will allow prolonged summer use as well as some winter use subject to factors such as frequency of use, type of traffic, nature of soil and drainage. This includes parking on a daily basis, disabled access and access to areas closed off in the colder, wetter months. Please contact our technical team for further guidance on whether our grass reinforcement solutions will suit your project.

Suregreen grass reinforcement meshes are used to provide many parking and access solutions where a grass surface may not have been previously considered.

Typical problems solved would include:

  • Daily car parking requirements
  • Overflow car parking requirements
  • Allowing off-road parking on grass verges
  • Access to grass areas normally closed off to trafficking
  • Minimising damage to highly trafficked grassed areas like builders compounds
  • Temporary grass access routes
  • Protection to allow routing by golf buggies
  • Equestrian issues such as poaching and rutting at paddock gateways, walkways and feeding rings.

Installing GR14 & GR11 grass reinforcement meshes is normally easy and trouble-free. The plastic mesh is laid onto the existing grass and fixed in place using steel U-Pins. If installed correctly and not used inappropriately, the expected lifetime of the grass reinforcement meshes should be 10 - 20 years.

The plastic mesh is UV-stable, rot-proof and the mesh will not degrade once in place. Please see our installation guide for instructions or contact our technical team for further guidance.

Suregreen GR meshes aren't just for permanent solutions - they are able to be installed for immediate use if needed for temporary applications. These would include grass access routes and builder compounds. Although not having the full working capacity of an integrated mesh, the effects of trafficking will be greatly minimised.

Suregreen GR11 and GR14 are a fully permeable solution and as can be used as part of a source control system within a Sustainable Urban Drainage System Solution (SuDS). The natural drainage of the land is unaffected, as is the natural ecology of the soils.

Suregreen GR grass reinforcement meshes are available in two mesh thickness/grades and in various roll sizes:

  • Suregreen GR14 mesh is our heavy-grade 14mm thick, 2kg/m² product that is suitable for the more intensive/frequent traffic applications
  • Suregreen GR11 mesh is our standard-grade 11mm thick, 1.2kg/m² product for less frequent and lighter applications or where economic restraints prevail.

Product Range:

Product

Size

Thickness

Weight

Material

Colour

Part No.

GR14 Heavy

2m x 20m

14mm

2kg/m²

HDPE (Part recycled)

Green

430004

GR14 Heavy

2m x 10m

14mm

2kg/m²

HDPE (Part recycled)

Green

430028

GR14 Heavy

1m x 10m

14mm

2kg/m²

HDPE (Part recycled)

Green

430011

GR14 Heavy

2.5m x 15m

14mm

2kg/m²

HDPE (Part recycled)

Green

437232

GR11 Standard

2m x 20m

11mm

1.2kg/m²

HDPE (Part recycled)

Green

430042

GR11 Standard

2.5m x 5m

11mm

1.2kg/m²

HDPE (Part recycled)

Green

434262

GR11 Standard

2m x 10m

11mm

1.2kg/m²

HDPE (Part recycled)

Green

430059

GR11 Standard

1m x 10m

11mm

1.2kg/m²

HDPE (Part recycled)

Green

430035
